AIR COOLED SCROLL CHILLER PRODUCT
6
5 PIPING DIAGRAM
5.1 Cooling Only
Pressure Switch
compressor
Temperature
Sensor
Filter
Thermal Expansion Valve
Temperature
Sensor
Vapour Liquid
Separato
Pressure
Switch
Temperature
Sensor
compressor
Pressure
Switch
Vapour Liquid
Separato
Temperature
Sensor
Thermal Expansion Valve
Filter
Pressure Switch
Heat Exchanger with Axial Flow Fan
Heat Exchanger with Shell and Tube
Heat Exchanger with Axial Flow Fan
