themselves. Be sure that they are in compliance with the specified technical
requirements.
※
The KWH meter should be meter of mutual inductance. Power consumed by
the unit is the electricity quantity detected by the meter (reading of the meter)
*mutual-inductance ratio of current transformer.
Please select KWH meter and current transformer according to actual
engineering status. For more details, please refer to Appendix A in this manual.
The optional KWH meter models are as follows:
PAC3200(Ethernet can be expanded to be RS485)
8.3 Network topological graph
Fig 8.1 Network topological graph which supports power billing
