Intelligent Controller
29
（2） Grade of accuracy: 1.
（3） Secondary rated current: 5A.
（4） Rated output load: 5VA.
（5） Rated primary current of current transformer: Select according to table 4.
Please use the current transformer made by a well-known brand with high
reliability.
Table 4: Reference Table of Load and Mutual-Inductance Ratio
Rated capacity of unit (HP) Rated capacity of unit (kW)
Mutual-inductance ratio of
10 Attachment B TCP/IP Setting
This text takes Windows 10 as example to demonstrate the setting of TCP/IP.
（1） Left click the icon “Start”
on the computer. When a new window pops
up, left click “Settings” to enter “Windows Settings”.
（2） Left click “Network & Internet” in the following picture to enter the interface
of “Network & Internet”. See ① in the picture below.
Fig 8.1 Windows settings
