82
DC Inverter Multi VRF System II
Service Manual
11 Left Side Plate 01314100013P 1
12 Clapboard Sub-Assy 01244100006 1
13 Fan Motor 15704115 1
14 Sensor Sub-Assy 39008000061G 1
15 Fan Motor 1570411501 1
16 Front Grill 26904100026 1
17 Cabinet 01514100002P 1
18 Front Side Plate 01314100012P 1
19 Handle 26235253 1
20 Front Connection Board 01344100002P 1
21 Diversion Circle 10474100001 1
22 Axial Flow Fan 10434100003 1
23 Chassis Sub-Assy 0119410000301P 1
24 Motor Support Assy 01804100293 1
25 Pressure Protect Switch 4602000902 1
26 Discharge Tube Sub-Assy 04534100057 1
27 Silencer 07444105 1
28 Oil Separator 07424105 1
29 Compressor 00204100001 1
30 Electrical Heater(Compressor) 765152128 1
31 Compressor Gasket 76710247 1
32 Cut off Valve 07330000002 1
33 Strainer 07212001 1
34 Gas-liquid Separator 07424100014 1
35 Capillary Sub-Assy 04004100013 1
36 Strainer 07415200002 1
37 Electromagnetic Valve 43000054 1
38 Magnet Coil 4304000417 1
39 Right Connection Board 01344100003P 1
40 Rear Side Plate Sub-Assy 01314100011P 1
41 Sensing Device 322101001 1
42 Sensor (High Pressure) 322101032 2
43 Gas By-pass Sub- Assy 04534100056 2
44 Magnet Coil 4304000406 1
45 Plate-type Heat Exchanger Assy 00904100013 1
46 Discharge Charge Valve 07133771 1
47 Electronic Expansion Valve 07334447 1
48 Electric Expand Valve Fitting 4304413205 1
49 Electronic Expansion Valve 07334390 1
50 Electric Expand Valve Fitting 4304413220 1
51 Low Pressure Survey Valve Sub-Assy 07334100040 1
52 Cut off Valve 07130239 1
53 Strainer 07212121 1
54 Silencer 07245012 1
55 4-Way Valve Assy 04044100022 1
56 Cut off Valve 07330000001 1
57 Strainer 07210037 1
58 One way Valve 07130118 1
59 4-way Valve 43000338 1
To Next Page
