A/A DC INVERTER U-MATCH AIR CONDITIONERS MAINTENANCE
222
NO. Name of Part Part Code Qty
20
Front grill
22413433 1
21
Small Handle
'26233100 1
22
Electric Box Assy
01395860 1
23
Radiator
49013027 1
24
Electric Box
20113014 1
25
Filter Board
30033073 1
30228206①
26 Main Board
30228207②
1
27
Reactor
43130184 1
28
Capacitor
'33010026 1
29
Terminal Board
42011154 1
①GUHD09NK3CO
②GUHD12NK3CO
Model: GUHD18NK3CO
Exploded View
Spare Parts List
NO. Name of Part Part Code Qty
1 Front Grill '22415002 1
2 Front Panel '01535008P 1
3 Chassis Sub-Assy '0120371401P 1
4 Compressor And Fittings '00103501 1
5 Compressor Gasket '76710236 3
6 Magnet Coil '4300040033 1
7 4-way Valve Assy '04145373 1
8 4-way Valve '430004032 1
To Next Page
