Gree U-MATCH GUHD09NK3CO

A/A DC INVERTER U-MATCH AIR CONDITIONERS MAINTENANCE
231
Spare Parts List
NO. Name of Part Part Code Qty
1 Top Cover
'01255009P
1
2 Air Guard
'01355204
1
01125373①
3 Condenser Assy
'01125392
②
1
4 Rear Grill
'01475012
1
04145342①
5 4-way Valve Assy
'04145362
②
1
6 4-way Valve
'43000338
1
7 Pressure Protect Switch
'46020006
1
8 Temperature Sensor
'3900028002
1
9 Electronic Expansion Valve
'07334194
1
07335263①
10 Electric Expansion Valve Sub-Assy
'07335271
②
1
11 Cut-off Valve
'07133157
1
071302391
12 Cut-off Valve
'07133185
1
13 Right Side Plate Sub-Assy
'01305441P
1
14 Handle
'26235253
2
15 Valve Support Sub-Assy
'01715257P
1
16 clamp
'02145008
1
17 electrical heater
'76518732
1
18 Gas-liquid Separator Sub-Assy
'07255201
1
19 Compressor and fittings
'00205236
1
20 Inhalation Tube 1
'04655520
1
21 Retaining Plate Sub-Assy
'01845235P
1
22 Chassis Sub-assy
'01195244P
1
23 Motor Support Assy
'01805396
1
24 Motor Support Sub-Assy
'01705111
1
25 Fan Motor
'150154516
1
26 Axial Flow Fan
'10335010
1
27 Insulated board (cover of electric box)
'20113003
1
28 Front Side Plate Sub-Assy
'01305508
1
29 Cabinet
'01435007P
1
30 Front Grill
'22415005
1
'01895309①
31 Condenser support plate
'01795020
②
1
32 Left Side Plate
'01305064P
1
33 left handle
'26235401
1
34 Electric Box Assy
'01395956
1
35 Radiator
'49018113
1
36 Reactor
'43130178
1
37 Main Board
'30228806
1
38 Electric Box
'26905211
1
39 XY Capacitor
'33030013
1
40 Main Board
'30224311
1
41 High-frequency transformer
'43110030
1
42 Filter Board
'30228118
1
43 Relay
'44020378
1
44 Terminal Board
'42011103
1
45 Capacitor CBB61
'33010009
1
42011221①
46 Terminal Board
'42011043
②
1
①GUHD36NM3CO
②GUHD42NM3CO
