Gree U-MATCH GUHD09NK3CO

A/A DC INVERTER U-MATCH AIR CONDITIONERS MAINTENANCE
233
Spare Parts List
NO. Name of Part Part Code Qty
1 Top Cover '01265356P 1
01025396①
2 Condenser Assy
'01125410
②
1
3 Rear Grill '01575205 1
4 Clapboard Sub-Assy 01244144 1
5 Strainer '07210037 1
6 Temperature Sensor '3900028002 1
7 Pressure Protect Switch '460200061 1
8 4-way Valve '43000338 1
9 Strainer 07210045 1
10 Rear Side Plate Sub-Assy '01314306P 1
11 Handle '26235253 1
12 Valve Support Sub-Assy '01715001 1
13 Gas Valve Sub-Assy 07103030 1
14 Cut-off Valve '07130209 1
'07334309①
15 Electronic Expansion Valve
'07330001
②
1
'4300010813①
16 Electric expand valve fitting
'4304000101
②
1
17 Bidirection Strainer '07220016 1
18 Pressure Protect Switch '46020007 1
19 electrical heater '765152123 1
20 Compressor Gasket '76815204 3
21 Compressor and fittings '00204126 1
01745001①
22 Liquid Accumulator Clamp
'02145435
②
1
'07225018 1
23
Gas-liquid Separator
Sub-Assy
07225016
'1501506105①
24 Fan Motor
'1570531302
②
2
25 Axial Flow Fan '10335008 2
26 Front Side Plate '01315364P 1
27 Handle '26235253 1
28 Front grill '22415002 2
29 Left Side Plate '01315366P 1
30 left handle '26235401 1
01395967①
31 Electric Box Assy
'01395966
②
1
32 Radiator 49018028 1
33 Main Board 30228807 1
34 Electric Box 26904131 1
35 Main Board 30228118 1
33010010①
36 Capacitor
'33010037
②
2
37 Reactor 43138004 1
42011043①
38 Terminal Board
'42011223
②
1
①GUHD48NM3CO
②GUHD60NM3CO
