A/A DC INVERTER U-MATCH AIR CONDITIONERS MAINTENANCE
236
Spare Parts List
NO. Name of Part Part Code Qty
1 Return Air Frame Sub-assy '01498641 1
'01025401①
2 Evaporator Assy
'01025394②
1
3 Water Tray Assy '01284166 1
4 Top Cover Board Sub-assy '01259064 1
5 Left Support of Evaporator Sub-Assy '01805280 1
6 Left Side Plate Assy '01315424 1
7 Water Pump Assy '15404121 1
8 Seal Of Left Side Plate Sub-Assy '01494128 1
9 Seal Of Connection Pipe '01498640 1
10 Electric Box Cover '01425269 1
'01395981①
11 Electric Box Assy
'01395947②
1
12 Terminal Board '42010194 1
13 Transformer '43110239 1
'33010026①
14 Capacitor CBB61
'33010010②
1
To Next Page
