A/A DC INVERTER U-MATCH AIR CONDITIONERS INSTALLATION
65
Item
Model
A B C D E F G H I J
GFH09K3CI
840 561 635 790 880 665 738 125 203 250
GFH12K3CI
932 430 738 892 980 721 738 125 203 266
GFH18K3CI
932 430 738 892 980 721 738 125 203 266
GFH24K3CI
GFH30K3CI
1101 515 820 1159 1270 530 1002 160 235 268
GFH36K3CI
GFH42K3CI
1011 748 820 1115 1226 775 979 160 231 290
GFH48K3CI 1015 788 820 1115 1226 815 979 160 261 330
GFH60K3CI 1353 632 992 1150 192 343 1463 385 799 --
Unit：mm
Installation Accessories List for Duct-type Indoor Unit
Name & Shape QTY Notes
Installation and Operating Instructions 1
Insulation materials for gas pipe 1 Used for gas pipe connector on indoor unit
Insulation materials for liquid pipe 1 Used for liquid pipe connector on indoor unit
Insulation materials for drainage pipe 2
Used for wrapping the condensate pipe and
rubber plug.
Nut M8 with gasket 8 Use for fixing the hanger hook
4
Nut and spring gasket 4
4 sets, used for ceiling mounting of the indoor unit
Hook 4 Used for ceiling mounting of the indoor unit
Strap 4 or 8 pcs 4 pcs for 18KBtu/h unit and 8 pcs for others
Wired controller 1
Remote controller 1
Battery 2
Fexible pipe 0.2 or 4 pcs
0 pc for 18 KBtu/h unit; 2 pcs for 22.5,27KBtu/h
unit; and 4 pcs for 36-45KBtu/h unit
Power cord 1 – 2 pcs 2 pcs for36-45 KBtu/h unit and 1 pc for others
Connection wire
