Gree U-MATCH GUHD09NK3CO

A/A DC INVERTER U-MATCH AIR CONDITIONERS INSTALLATION
90
meters.
 When the indoor and outdoor units are on different height, please refer to Fig. 30201 for pipe layout.
Liquid pipe (i.e. fine pipe)
- - - - - -Gas pipe (i.e. coarse pipe)
Figure 3-2-1
Gas pipe
Outdoor unit
Oil elbow in gas
pipe
One oil trap shall be
arranged every 4-6
Liquid pipe
Intdoor unit
