Greenbridge PC1000 - Construction Layout

-A12-
3.3 Construction Layout
1. Arch
2. Upper Table Front
3. Adjustment Leg
4. Reel
5. Foot Bar (Front)
6. Caster (Brake)
7. Reel Brake Release
8. Caster (Free)
9. Foot Pedal (Option)
10. Control Panel
11. Power Cord
12. Strapping Head Unit
13. Main Motor M1
14. Feed Motor M2
15. Tension Motor M3
Danger to Lift!
Suspend loads can fall down.
By inappropriate mounting or fracture of hoisting device the
load can fall down and cause serious injuries or death.
Do not step under suspended loads!
Use appropriate hoisting devices and fasteners.
