1-1 CAM GROUP M7-1-100011
REF.
NO.
PART NO. DESCRIPTION Q'TY
1
M7-1-101100
Strapping Head Frame
1
X
2
M7-1-101200
Guide
2
191655
3
M7-1-101300
Ejector Plate (L)
1
191500
4
M7-1-101400
Ejector Plate (R)
1
191496
5
M7-1-101500
Shaft
1
X
6
M7-1-101600
Collar
1
X
7
M7-1-101700
Cover
1
191582
8
M7-1-101800
Sensor Base
1
X
9
M7-1-101900
Coupling
1
X
10
M7-1-102000
Spring
1
191474
21
M7-1-110001
Gear Box and Cam Ass'y
1
SEE PAGE C7 X
22
M7-1-120000
M1 Motor Ass'y
1
SEE PAGE C9 X
23
M7-1-130000
Slide Table Frame Ass'y
1
(SEE PG. C11) 191637
24
M7-1-140000
Heater Arm Ass'y
1
SEE PAGE C13
25
M7-1-150000
Exhaust Fan Ass'y
1
(SEE PG. C15) 191658
26
T7-1-16000
Block Ass'y
1
SEE PAGE C17 X
30
H42-1227
Washer
3
205661
31
TA-089
Spring Hook
1
202019
32
T7-1-10330
Bumper
4
191554
33
T7-1-10360
Bumper Bracket
2
X
34
T7-1-64130
Return Spring
1
191488
36 LA-40002 Label 1
X
38
MB1515
Metal Bushing, 1515
1
191507
41
SP0514
Spring Pin, 5×14
2
X
43
HBS0308N
HBS, M3×8 (N)
4
191497
44
HBS0516N
HBS, M5×16 (N)
4
191700
45
HBS0525HN
HBS, M5×25 (H)(N)
2
X
46
HBS0640HN
HBS, M6×40 (H)(N)
3
X
47
HBS0645HN
HBS, M6×45 (H)(N)
4
X
48
HBS0620N
HBS, M6×20 (N)
2
191726
49
HBS0840HN
HBS, M8×40 (H)(N)
2
X
50
HBS0865HN
HBS, M8×65 (H)(N)
2
X
51
HSS0506GN
HSS, M5×6 (G)(N)
2
191584
52
HSS0610GN
HSS, M6×10 (G)(N)
2
187433
55 HN08 HN, M8 4
187490
58 THS0508N THS, M5×8 (N) 2
191579
Greenbridge PART #
