Greenbridge PC1000 - Page 70

1-1-1 GEAR BOX AND CAM ASS'Y M7-1-110001
REF.
NO.
PART NO.
DESCRIPTION
Q'TY
1
M7-1-111100
Retracting Cam
1
X
X
X
X
X
X
X
X
X
X
X
X
X
X
187830
X
X
X
X
191544
X
X
187305
191562
191612
2
M7-1-111200
Tension Cam
1
3
M7-1-111300
Heater Cam
1
4
M7-1-111400
Front Bar Cam
1
5
M7-1-111500
Press Bar Cam
1
6
M7-1-111600
Rear Bar Cam
1
7
M7-1-111701
Slide Table Cam
1
9
M7-1-111900
Support
2
10
M7-1-112001
Cam Shaft
1
11
M7-1-112100
Position Cam
1
12
M7-1-112201
Arch Cam
1
16
M7-1-110100
Gear Box
1
21
TB-223
Washer
2
22
T7-1-11240
Handle
1
26
BR6003ZZ
Bearing, 6003ZZ
2
30
KYA020210
Key, 2×2×10
1
31
KYA050530
Key, 5×5×30
1
33
KYA0505101
Key, 5×5×101
2
36
CAP06
CAP, M6
1
39
HBS0616N
HBS, M6×16 (N)
1
40
HBS0625N
HBS, M6×25 (N)
4
42
HSS0505GN
HSS, M5×5 (G)(N)
1
43
HSS0606GN
HSS, M6×6 (G)(N)
9
46
SW06
SW, M6
6
51
HB0616
HB, M6×16
1
-C8-
Greenbridge PART #
