4
1.1.7
1.1.8
1.1.9
1.1.10
1.1.11
1.1.12
1.2
Front Side
Ø 199 mm 129.5 mm
62 mm
Ø 99 mm
Ø 178 mm
68 mm
48 mm
Warning: This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by children
without supervision.
Where an open-flued oil or gas-fuelled appliance is installed, precautions
must be taken to avoid a back-flow of gases into the room.
When installing wall mounted fans, ensure that there are no buried
cables or pipes in the way. It is recommended that this fan is mounted
>1.8m above floor level.
The fan should not be sited where it would be subject to a direct heat
source in excess of 40°C.
Observe appropriate safety precautions if working on steps or ladders.
Wear eye protection when breaking out wall or window materials, etc.
The CV2SVGIP fan must only be installed by using the supplied Safety
Extra Low Voltage (SELV) controller, corresponding to the markings on
the appliance.
Physical Specification
