IMPORTANT
Use only the replacement parts and accessories of
the initial manufacturer.
10.1 GENERAL INFORMATION
IMPORTANT
Only your dealer or approved service center can
perform maintenance that is not given in this
manual.
Before the maintenance operations:
• Stop the machine.
• Remove the battery pack.
• Cool the motor.
• Store the machine in cool and dry place.
• Use correct clothing, protective gloves and safety
glasses.
10.2 CLEAN THE MACHINE
• Clean the machine after each use with a moist cloth
dipped in neutral detergent.
• Do not use aggressive detergents or solvents like
"glass cleaner" to clean the plastic parts or handles.
• Keep the trimmer head free from grass, leaves, or
excessive grease.
• Keep the air vents clean and free of debris to avoid
overheating and damage of the motor.
• Do not spray water onto the motor and electrical
components.
10.3 REMOVE EXCESS LINE
1. Push the tabs (5) on the sides of the trimmer
head at the same time.
2. Pull and remove the spool cover (1) and spool
(2).
3. Remove any remaining line.
4. Clean dirt and debris from all parts. Replace
spool if it is worn or damaged.
5. Align the spool tabs (5) with the tab openings (4)
in the base of the spool (3).
6. Push the spool cover until it clicks into position.
10.4 REPLACE THE SPOOL
NOTE
If any parts of the spool retainer assembly are
damaged or worn, replace the damaged part and
reassemble them as following showing
1. Disassemble the trimmer head. Pull and remove
the spool cover (5).
2. Clean dirt and debris from all parts.
3. Loosen the screws (1). Remove the spool (2),
slot cover (3), location housing (4) from the spool
assembly.
4. Replace with a new spool.
5. Insert the location housing and slot cover onto the
spool cover, and then put the spool onto the slot
cover to the desired position.
6. Tighten with the screws.
11
English
EN
