10.5 INSTALL THE CUTTING LINE
NOTE
Do not put more than 23 feet of cutting line in at a
time.
1. Remove the remaining cutting line on the spool.
2. Line up the slots on the spool cover with the slots
(1) on the trimmer head.
1
2
3. Insert the line into the mounting hole, which is
located inside the eyelet (2). Push the cutting line
until it exits the opposite hole.
4. Pull the cutting line through until there is an equal
quantity of cutting line on each side.
5. Rotate the spool cover clockwise in the arrow
direction to wind the cutting line into the trimmer
head. Keep approximately 5 in of cutting line
above out of each side of the trimmer head.
11 TRANSPORTATION AND STORAGE
WARNING
Remove the battery pack from the machine before
transportation and storage.
11.1 MOVE THE MACHINE
When you move the machine, you must:
• Stop the machine.
• Remove the battery pack.
11.2 STORE THE MACHINE
• Remove the battery pack from the machine and
charge it.
• Make sure that children cannot come near the
machine.
• Keep the machine away from corrosive agents such
as garden chemicals and de-icing salts.
• Secure the machine during transportation to prevent
damage or injury. Clean and examine the machine
for any damage.
12 TECHNICAL DATA
Type Cordless, battery pow-
ered
Motor 80V
