SIMULATION
Exercises the 4-20mA output, digital display and control relays (does not
affect the totalizer or optional data logger).
Output Press Æ and then È or Ç to change the simulated output. Press
ü to begin simulation. The 4-20mA output and relay states will be
displayed on the screen below.
Press the ü to terminate simulation and return to the Menu
Selections
screen.
Page 14
DFM 5.0 Doppler Flow Meter
--Simulation--------
>Output 250USG
4-20mA 5.60mA
Relays 1 23456
