DATA LOGGING (Optional)
Setup
Select
Data Logging from Menu Selections.
Log Site ID Enter a number from 00 to 99. The site ID will
become part of the downloaded file name to help
distinguish downloads from different instruments.
Press ü to store the setting.
Mode Select Velocity (e.g. ft/sec or m/sec). Flow (e.g.
USGPM or l/sec). Press ü to store the setting.
Set Date
Press Ç or È to scroll and select Month, Day and
Year. Press ü to store the setting.
Set Time
Press Ç or È to select the current time in Hours,
Minutes and Seconds. Press ü to store the setting.
Interval
Press Ç or È to select the logging interval. Flow rate
reading will be stored at each time interval. Press ü to
store the setting.
Reset Log Select Yes to apply any changes that have been made
to the logger
Interval or Mode. The current log file
will be erased from memory and a new log file will
start.
RETRIEVE LOG FILE
Plug a USB Flash Memory Drive (not supplied by Greyline) into the USB
output cable from the instrument. The instrument display will show the
message
Downloading until the log file is transferred to the memory
card and then display
Completed. The USB flash drive may be
removed.
Download file names will appear in this format:
Tag is set according to the
Log Site ID entered in the instrument Data
Logging
menu.
Page 36
DFM 5.0 Doppler Flow Meter
--Data Logging-------
>Log Site ID 00
99
Mode Flow
Velocity
Set Date Feb 18/2008
Mar 19/2009
Set Time 11:27:40
12:28:41
Interval 10sec
60min
30min
10min
5min
2min
1min
30sec
Reset Log NO
YES
DFM_ _00A.LOG
MODEL TAG DOWNLOA
