CALIBRATION MENU
Page 7
DFM 5.0 Doppler Flow Meter
--Password----------
Password 0000
--Data Logging-------
>Log Site ID 0
Mode Flow
Set Date Feb 18/2007
Set Time 11:27:40
Interval 10sec
Reset Log NO
--Units/Mode--------
>Mode Flow
Linear in
Volume USG
Time min
--Calibration-------
>20mA at 2500.0 USG/m
4mA at 0.000 USG/m
Pipe ID 12.00in
Damping 20%
--Relay Parameters--
>Relay 1
Function Flow
Mode Pump
On 1000 USG
Off 0.000 USG
USG/min
Tot 20130.8 USG
Relays 123456
0.000
--Message-----------
Data log Logging
Log Use 0%
Sensor Good
--24 hr log----------
>Date Feb. 12/2008
Total 0.000ft/s
Average 0.000ft/s
Maximum 0.000ft/s
Max Time 01:57:00
Minimum -1.046ft/s
Min Time 02:35:00
--Status------------
>Velocity 0.00ft/s
Tot 0.000USG
Signal Cutoff 5%
Signal Strength 0%
Sig Confidence 0
Relays123456
20mA at
--Special Functions-
>Language English
Backlight On High
Reset Totalizer NO
Negative Totals NO
Reverse Flow NO
Cal Constant 1.000
Restore Defaults NO
New Password 0000
--Simulation--------
>Output 250USG
4-20mA 5.60mA
Relays 1 23456
--Configuration-----
>Utility Board 1.01
Doppler 1.02
Logger 1.03T
Relays 2
4-20 Outputs 1
--Menu Selections----
>Units / Mode
Calibration
Relay Parameters
Data Logging
Special Functions
Simulation
Configuration
OPTIONAL FEATURES
