Monitor Mode
Table 18 - Monitor Mode Commands
Command Command Name Function
VS x.x.x.x Version Query software header record (16 bytes) of unit with (opt) IP
address x.x.x.x
GC x.x.x.x Get Configuration Get configuration of unit with (opt) IP address x.x.x.x as hex
records (120 bytes)
SC x.x.x.x Send Configuration
(CAUTION)
Set configuration of unit with (opt) IP address x.x.x.x from
hex records
PI x.x.x.x Ping Pings unit with IP address x.x.x.x to check device status
AT ARP Table Show the unit’s ARP table entries
TT TCP Connection
Table
Shows all incoming and outgoing TCP connections
NC Network Connection Shows the unit’s IP configuration
RS Reset Resets the unit’s power
QU Quit Exit diagnostics mode
G0, G1,…,Ge,
Gf
Get configuration
from memory page
Gets a memory page of configuration information from the
device.
S0, S1,…,Se,
Sf
Set configuration to
memory page
Sets a memory page of configuration information on the
device.
GM Get MAC address Shows the unit’s 6-byte MAC address.
SS Set Security record Sets the Security record without the encryption key and
length parameters. The entire record must still be written,
but the encryption-specific bytes do not need to be provided
(they can be null since they are not overwritten).
Responses to some of the commands are given in Intel Hex format.
Note: Entering any of the commands listed above will generate one of the following command response codes:
Table 19 -Command Response Codes
Response Meaning
0> OK; no error
1> No answer from remote device
2> Cannot reach remote device or no
answer
8> Wrong parameter(s)
9> Invalid command
