NET485 User Guide 8-3
8.2 Electromagnetic Compatibility Tests
Purpose:
This test series was performed to determine if the NET485 would meet selected requirements of the IEC
61000-6-1 and IEC 61000-6-3 specifications.
Deviations, Additions and Exclusions:
There were no deviations, additions to, or exclusions from the test specification during this test series.
EMC Laboratory Identification:
The electromagnetic compatibility tests were performed by Elite Electronic Engineering Incorporated of
Downers Grove, Illinois. Engineering Test Report No. 1302913-01.
Summary of Tests Performed:
The following electromagnetic compatibility tests were performed on the EUT in accordance with IEC
61000-6-1 and IEC 61000-6-3:
Test
Description
Test Range
Result
RE
Radiated Emissions
30MHz to 1GHz
Pass
ESD
Electrostatic Discharge
4kV
Pass
RI
Radiated Immunity
80MHz to 2.7GHz
Pass
EFT
Electrical Fast Trans - Power
500V
Pass
CI
Conducted Immunity
150kHz to 80MHz
Pass
IEC 61000-6-1:2005 “Electromagnetic Compatibility (EMC) - Part 6-1: Generic standards – Immunity for
residential, commercial and light-industrial environments”
IEC 61000-6-3:2011 “Electromagnetic Compatibility (EMC) - Part 6-3: Generic standards – Emission
standard for residential, commercial and light-industrial environments”
IEC 61000-4-2:2008 "Electromagnetic Compatibility (EMC), Part 4: Testing and Measurement Techniques,
Section 2: Electrostatic Discharge Test"
IEC 61000-4-3:2010 "Electromagnetic Compatibility (EMC) - Part 4: Testing and Measurement Techniques,
Section 3: Radiated, Radio-Frequency, Electromagnetic Fields"
IEC 61000-4-4:2011 "Electromagnetic Compatibility (EMC) - Part 4: Testing and Measurement Techniques,
Section 4: Electrical Fast Transient/Burst Immunity”
IEC 61000-4-6:2008 "Electromagnetic Compatibility (EMC), Part 4: Testing and Measurement Techniques,
Section 6: Immunity to conducted disturbances, induced by radio frequency fields"
