Grifco DRIVE User Manual

15
SPECIFICATION
GSB-547 GSB-1017 GSB-1892
Permissible torque Nm 547 1017 1892
Maximum safety catch torque Nm 2058 3509 8230
Maximum operating speed min -1 20 18 12
Test certificate number Door FV 3 / 014 Door FV 3 / 015 Door FV 3 / 016
Shaft mounting mm 40 50 65
Bearing type Self-aligning bearing Self-aligning bearing Fixed bearing
Unit weight kg 12.5 21.0 34.0
Drum Diameter (mm) Max. Door Weight in Kg
165 450 997 1990
168 442 979 1954
219 355 800 1499
273 283 635 1217
SAFETY BRAKE

Grifco DRIVE Specifications

General

Manufacturer	Grifco
Category	Door Opening System
Model	DRIVE
Voltage	230V AC
Operating Temperature	-20°C to +50°C
Opening Speed	0.3m/s
Closing Speed	0.3m/s
