Grifco DRIVE User Manual

17
SPECIFICATION
E
C
B
G
F
P
A
O
M
L
D
Q
H
T
V
U
R
S
I
K
J
N
D M P
DDMP-01
B
C
E
F
G
H
L
I
A
D
M
O
J
K
N
Model A B C D E F G H I J K L M N O
Load
Capacity
Weight
DDMP-02
559 464 168 6 78 90 18 110 132 22 450 38 64 59 100 7000 16
Units mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm kg kg
The maximum load each bracket can support is the ‘Load capacity’.
The calculation of determining the weight on each bracket must
factor in the weight of the drum, the roller shutter curtain, the
Operator and the dynamic forces of stopping and starting the door.
CAUTION
MOUNTING PLATFORM

Grifco DRIVE Specifications

General

Manufacturer	Grifco
Category	Door Opening System
Model	DRIVE
Voltage	230V AC
Operating Temperature	-20°C to +50°C
Opening Speed	0.3m/s
Closing Speed	0.3m/s
