Grillo CLIMBER 9.18 - Maintenance Summary and Adjustments

Climber 9.18/ Translation of the original instructions
TRACTION RELEASE LEVER
The traction release device is located behind the seat; if the machine breaks down, to allow it to be
towed or moved by hand, move the lever outward (fig. 20A). In the position shown (fig. 20B) the machine
is in working condition. Check that during working the hydraulic engine piston does not remain pressed
down; if necessary, adjust the nut (fig. 21).
DIFFERENTIAL LOCK ADJUSTMENT
The differential lock has to be activated when the pedal is half way of its travel (fig. 8). To adjust the
activation point of the differential lock use the screw (fig. 9).
MAINTENANCE SUMMARY TABLE
PROCEDURE EVERY 8
HOURS
AFTER
20
HOURS
EVERY
50
HOURS
EVERY
100
HOURS
ONCE A YEAR
OR EVERY
200 HOURS
Engine oil
check the level ●
change ● ●
Air filter
check ●
replace ٭
Spark plug
check/adjust ●
replace ●
Hydraulic
engine oil
check the level ● ●
replace ●
Check that the engine intake grid is
clean
●
Check that the hydraulic engine
cooling fins are clean
●
Final drive
gearbox oil
check the level
● ●
replace
٭
Check that blades are well-sharpened
and well-fixed
●
Lubricate with grease
● ●
● recommended procedure
٭ procedure to be carried out if necessary
12
