Grillo FD 450 - Extraordinary Adjustments; Adjusting the Parking Brake; Adjusting the Cutting Deck

19
A
B
Fig. 24
C
Fig. 25
CAUTION:onlylowertheroll-barwhenabsolutelynecessary,
for short periods and raise it immediately as soon as conditions
permit.
To raise the roll-bar, proceed as follows:
1. Parkthemachineonaatsurface;
2. Disengage the PTO, lower the cutting deck and engage the parking
brake;
3. Switch off the engine and remove the key;
4. Removetheboltsshowning.25/C,rotatethemastsofthearch
upwards,thenrettheboltsasperg.24/B;
5. Removetheboltsshowning.24/A,rotatetheupperpartofthe
archupwards,thenrettheboltsasing.23/A.
14. EXTRAORDINARYADJUSTMENTS
CAUTION:theadjustmentproceduresdescribedbelowrequire
technicalskillsandexpertise.
ItisadvisabletocontactanauthorisedGrillocentretoundertake
theseprocedures.
14.1 ADJUSTINGTHEPARKINGBRAKE
If the parking brake is ineffective, it is possible to adjust it using the
adjusterlocatedunderthefairingontheleftside(g.26):bylooseningthe
lock nut and loosening or tightening the adjuster it is possible to vary the
tension of the cable connected to the lever.
Fig. 26
14.2 ADJUSTINGTHECUTTINGDECK
Good planarity of the cutting deck is essential for an evenly mowed
lawn. Place the lawnmower on a smooth, level surface, make sure the
distributorleverisoatingandlowerthecuttingheighttotheminimum.
Then:
1. Check the correct tyre pressure (1.5 bar);
2. Check the distance of the edge of the cutting deck from the ground
at the points indicated (g. 27). InA the measurement must be
15/20 mm, in B it must be greater than A by about 5/10 mm;
3. If necessary intervene:
- Onthefrontwheelslots(g.28)toadjustthedifferenceinheight
between the left and right-hand sides;
- Ontheadjusterattherearofthecuttingdeck(g.29)toadjust
the tilt.
A B
Fig. 27
