Grizzly DEEP DIGGER - Hydraulic Kit (Roller) 7 Tyne Trailing

32
Specications are subject to change without prior notication From serial number 7027
DESCRIPTIONPART NO.QTY
ITEM
BOLT M 8 X80FABEA08081
RETRACT LINE RELIEF VALVE KITHFALL50-B12
HYD HOSE 3/8" E26 (3000)HGCZD000A13
HYD HOSE 3/8" E26 (3300)HGCZD300A
14
HYD HOSE 3/8" E26 (4100)
HGCZE10015
HYD HOSE 3/8" E26 (4200) QR
HGCZE200B26
ELBOW 3/4 JICM 3/4 UN ORING MALEHHABAM0747
HYD Coupling COVER BLUEHHZWUA07B18
HYD Coupling COVER REDHHZWUA07R
1
9
20mm DOUBLE HOSE CLAMP SHELLHJBCA000910
STACKING BOLT RCD-3BSHJBEA000111
HEAT SHRINK GREEN - FOLDHXEBF000112
HYD CYL 3.00 X 8 (1.25" ROD)HZP300/08D113
HYD.CYL. 3.25" X 8" 1.25" RODHZP325/08D
114
HYDRAULIC KIT (ROLLER)7 TYNE
TRAILING
L:\Inventor\Parts\GN-\GNBRN000.idw
GNBRN000
6
6
12
9
8
10
6
6
2
3
4
3
5
14
13
5
4
