Grizzly DEEP DIGGER - Hydraulic Kit (Roller) 9 Tyne

33
Specications are subject to change without prior notication December 2019
DESCRIPTIONPART NO.QTYITEM
BOLT M 8 X80FABEA080131
RETRACT LINE RELIEF VALVE KITHFALL50-B
1
2
HYD HOSE 3/8" E26 (2800) QR
HGCZC800Q23
HYD HOSE 3/8" E26 (5300) 3/4JIC FEMALE 3/4JIC FEMALEHGCZF300A14
HYD HOSE 3/8" E26 (5800)HGCZF800A15
HYD HOSE 3/8" E26 (5900)HGCZF900A
1
6
ELBOW 3/4 JICM 3/4 UN ORING MALE
HHABAM0747
STRAIGHT 3/4 JIC M 1/2 BSPP ORING M
HHBEM00028
HYD Coupling COVER BLUEHHZWUA07B19
HYD Coupling COVER REDHHZWUA07R110
20mm DOUBLE HOSE CLAMP SHELLHJBCA00013
11
STACKING BOLT RCD-3BSHJBEA000112
DEPTH STOP - CAPTIVE PAIRHMDEA004113
HEAT SHRINK GREEN - FOLDHXEBF000114
HYD. CYL. 4.5 X 12 DS 2" SHAFTHZP450/12D2115
HYD. CYLINDER 5 X 12 DS 55 RODHZP500/12D55
1
16
HYDRAULIC KIT (ROLLER) 9 TYNE
L:\Inventor\Parts\GN-\GNBRN002.idw
14
3
9
4
6
3
5
6
15
13
16
4
5
11
1
12
GNBRN002
