Grizzly DEEP DIGGER - Hydraulic Kit (Roller) 11 Tyne

34
Specications are subject to change without prior notication From serial number 7027
D ( 1 :15 )
E ( 1 : 15 )
F ( 1 : 15 )
G ( 1 :15 )
DESCRIPTIONPART NOQTYPOS
BOLT M 8 X80FABEA080131
11 TYNE RIPPER FRAME
GCN011H
12
RETRACT LINE RELIEF VALVE KITHFALL50-R13
HYDRAULIC HOSE 3/8" (2800)HGCZC800F14
HYDRAULIC HOSE 3/8" (2800)HGCZC800G
15
HYDRAULIC HOSE 3/8" (5700)HGCZF70016
HYDRAULIC HOSE 3/8" (5950)HGCZF95017
HYDRAULIC HOSE 3/8" (6900)HGCZG900B18
ELBOW 3/4 JICM 3/4 UN ORING
MALE
HHABAM0749
BULKHEAD 1/2BSP OringHHACAA06210
INSERT 1/2"BSP FEMALE 3/8"
HOSE STRAIGHT
HHAKBA05211
INSERT 3/4JICF 3/8 HOSE
6040-0612
HHAKBU07612
INSERT 3/4 UNORING 3/8 HOSE
HHAKMU07213
STRAIGHT3/4JICM
1/2BSPPORINGM (S74-0812)
HHBEM000214
FIELD ATTACH FERRULE 3/8 NON
SKIVE
HHCPUA071015
POPPET CHECK Q R TIP 3/4" UN
O RING
HHDMNW07216
INLINE FILTERHHKY0000217
HYD Coupling COVER BLUE
HHZWUA07B118
HYD Coupling COVER REDHHZWUA07R119
20mm DOUBLE HOSE CLAMP
SHELLS
HJBCA0001420
STACKING BOLT RCD-3BSHJBEA000121
DEPTH STOP - CAPTIVE PAIRHMDEA004122
HEAT SHRINK GREENHXEBF000123
HYD. CYL. 4.5 X 12 DS 2" SHAFTHZP450/12D2124
HYD. CYLINDER 5 X 12 DS 55 RODHZP500/12D5
5
125
D
E
F
G
HYDRAULIC KIT (ROLLER) 11 TYNE
L:\Inventor\Parts\GN-\GNBRN003.idw
GNBRN003
22
25
8
7
9
9
19
18
5
4
15
13
6
7
17
14
12
11
3
9
8
6
8
8
7
6
6
7
4
23
