Grizzly DEEP DIGGER - Retract Line Relief Valve Kit

47
Specications are subject to change without prior notication December 2019
DESCRIPTIONPART NO.QTYITEM
TEE 3/4JICF 3/4JICM 3/4JICMHHAABA07
11
1/2" BSPP RETAINING RING 36B-08
HHACAA01
22
1/2" BSPP O RING ROD-BP08
HHACAA0223
1/2" BSPP NUTHHACAA0314
BULKHEAD 1/2" BSPHHACAA0625
TEST POINT ADAPTOR 3/4 JIC - M16HHACAS07
1
6
STRAIGHT 1/2BSPTM 3/4 JICF SWIVEL
(S71-0812)
HHACBF1227
STRAIGHT 3/4 JIC M 1/2 BSPP ORING M HHBEM00038
IN LINE HYDRAULIC FILTER HHKY000029
INLINE RELIEF VALVE 1/2" BSP HHMWA008
1
10
RETRACT LINE RELIEF VALVE KIT
L:\Inventor\Parts\GH-\GHPC0007.idw
HFALL50-B
TO THE BASE END OF THE MASTER CYLINDER
SET TO 1000 PSI MAX.
TO THE ROD END OF THE SMALLEST CYLINDER
TO THE GAUGE
6
8
10
7
8
9
3
2
5
7
1
8
9
3
2
5
4
TO THE TRACTOR
