Grizzly DEEP DIGGER - Hyd. Cyl. 4.75 X 12 DS 1.5 Shaft

48
Specications are subject to change without prior notication From serial number 7027
DESCRIPTIONPART NO.QTYITEM
STRAIGHT GREASE NIPPLE 6mm BMAAA00621
SET SCREW 6 X 15FABDA01622
PIN 1 1/4" ANTI ROT. GREASABLEFGHPA07223
RAM PIN CLIPFKBDA0002
4
PTE S/KIT SLP 4.75" X 1.5" ROD
HKNB0SLP15
ROD SEAL "513"1.5"X1.875"X.375
HKAS 513-883541015.2
ROD WIPER"520"1.5"X1.875"X .18HKAS/520-888121015.3
O RING BS 248 70 DURO - 5"HKBS ORING248-701
5.4
O RING BS 121 90 DUROHKBS ORING121-90
15.5
O RING BS 248 70 DURO - 5"
HKBS ORING246-9015.6
PISTON SEAL 4.75" HALLITE "81"HKBS 53-236093015.7
PTE ROD 12" x 1.5" (1.25"UNF)HLFEG15016
CLEVIS 1.25" PIN 1.25"UNF D/SHMCBA000
17
PHASING VALVE FOR PTE CYINDERHNZA0000
1
8
HEADED BUSHMDAEA00629
HYD. CYL. 4.75 X 12 DS 1.5" SHAFT
L:\Inventor\Parts\GH-\GHPC0007.idw
4
7
3
1
9
2
5.3
5.2
5.6
5.4
5.5
6
HZP475-12D
8
