Grizzly DEEP DIGGER - Page 49

49
Specications are subject to change without prior notication December 2019
DESCRIPTIONPART NO.QTYITEM
STRAIGHT GREASE NIPPLE 6mm BMAAA00621
SET SCREW 6 X 15FABDA01622
PIN 1 1/4" ANTI ROT. GREASABLEFGHPA07223
RAM PIN CLIPFKBDA00024
PTE S/KIT SLP 5.0" X 1.5" ROD
HKPB0SLP15
PISTON SEAL 5.0" HALLITE "81"HKBS 53-659431015.1
ROD SEAL "513"1.5"X1.875"X.375HKAS 513-883541015.2
ROD WIPER"520"1.5"X1.875"X .18HKAS/520-8881210
1
5.3
O RING BS 248 90 DURO - 5"
HKBS ORING248-9015.4
O RING BS 049 70 DURO - 5"
HKB ORING049-7015.5
O RING BS 121 90 DUROHKBS ORING121-9015.6
PTE ROD 12" x 1.5" (1.25"UNF)HLFEG15016
CLEVIS 1.25" PIN 1.25"UNF D/SHMCBA000
17
PHASING VALVE FOR PTE CYINDERHNZA000018
HEADED BUSHMDAEA00629
HYD CYL 5" X 12" D/S 1.5" ROD
L:\Inventor\Parts\GH-\GHPC0007.idw
1
2
9
3
4
7
5.3
5.2
5.4
5.5
5.1
5.6
6
HZP500-12D
8
