Grizzly DEEP DIGGER - Hydraulic Kit-11 Tyne Level Lift

50
Specications are subject to change without prior notication From serial number 7027
A ( 1:10 )
DESCRIPTIONPART NOQTYPOS
BOLT M8 X 45FABEA04511
RETRACT LINE RELIEF VALVE KIT
HFALL50-B12
HOSE 3/8 DB (1100) 3/4JIC FEMALE 3/4 JIC FEMALEHGCZB100A13
HOSE 3/8 DB (2800) QR 1/2" BSP FEMALE 3/4UNO MALEHGCZC800Q24
HOSE 3/8 DB (5000) 3/4JIC FEMALE 3/4"JIC FEMALEHGCZF000A
15
HOSE 3/8 DB (5500) 3/4JIC FEMALE 3/4JIC FEMALEHGCZF500A16
HOSE 3/8 DB (6000) 3/4JIC FEMALE 3/4JIC FEMALEHGCZG000A17
ELBOW 3/4 JICM 3/4 UN ORING MALEHHABAM0768
HYD Coupling COVER BLUEHHZWUA07B19
HYD Coupling COVER RED
HHZWUA07R110
20mm DOUBLE HOSE CLAMP SHELLHJBCA0001311
TOP PLATE DOUBLE FOR GROUP 3HJBFA0001312
DEPTH STOP - CAPTIVE PAIR
HMDEA004113
HYD. CYL. 4.5 X 12 DS 2" SHAFTHZP450/12D2115
HYD. CYLINDER 5 X 12 DS 55 RODHZP500/12D55116
HYD. CYLINDER 5.5 X 12 DS 2.25" RODHZP550/12D
117
DEPTH STOP SIDE PLATE FITTING INSTRUCTIONSPD000090118
A
HYDRAULIC KIT-11 TYNE LEVEL LIFT
L:\Inventor\Parts\GH-\GHPC0011L.idw
6 7
6
7
7
4
4
GHPC0011L
2
16
17
3
13
6
5
15
3 544
4
4
5
3
8
8
8
8 8
