Grizzly DEEP DIGGER User Manual

51
Specications are subject to change without prior notication December 2019
DESCRIPTIONPART NO.QTYITEM
STRAIGHT GREASE NIPPLE 6mm BMAAA00621
SET SCREW 6 X 15FABDA01622
PIN 1 1/4" ANTI ROT. GREASABLEFGHPA07223
RAM PIN CLIPFKBDA00024
PTE S/KIT SHP 4.5" X 2.0" ROD
HKMB000115
ROD WIPER "520" 2.0"X2.5"X.25HKAS 520-888151015.1
ROD SEAL "513"2.0"X2.375"X.375HKAS 513-883591015.2
O RING BS 244 70 DURO HKBS ORING244-70
1
5.3
BACK UP FOR O RING BS 244 -4.5"
HKBS ORINGBU24415.4
O RING BS 047 70 DURO HKBS ORING047-7015.5
O RING BS 124 90 DUROHKBS ORING124-9015.6
P.T.E. S/KIT 4.5" X 2.0" RODHKBS 53-6594230-a15.7
PTE ROD 12" x 2" (1.25" UNF)HLFEG200
1
6
CLEVIS 1.25"PIN 1.75"UNF
HMCBA00117
CAP NUT 4.5" - 2"ROD
HNAP45X2018
HYD. CYL. 4.5 X 12 DS 2" SHAFTHNBP45X1219
PISTON 4.5" PHASINGHNPP450P
1
10
HEADED BUSH
MDAEA0062
11
HYD. CYL. 4.5 X 12 DS 2" SHAFT
L:\Inventor\Parts\HZ-\HZP450-12D2.idw
4
3
1
2
11
7
5.1
5.2
5.6
5.7
6
5.3
7
HZP450-12D2
8
5.5
10
