Grizzly DEEP DIGGER User Manual

52
Specications are subject to change without prior notication From serial number 7027
DESCRIPTIONPART NO.QTYITEM
STRAIGHT GREASE NIPPLE 6mm BMAAA00623
SET SCREW 6 X 15FABDA01624
PIN 1 1/4" ANTI ROT. GREASABLEFGHPA0722
5
RAM PIN CLIPFKBDA00026
PTE S/KIT SHP 5.0" X 55mm ROD
HKPB000217
ROD SEAL "605" 55 X 65 X 10HKAS 605-430610017.4
ROD WIPER TYPE 831 55mm ROD 65HKAS 831-453140017.5
O RING BS 030 90 DURO - 2"HKAS/ORING030-90
17.7
O RING BS 049 70 DURO - 5"
HKB ORING049-7017.6
PISTON SEAL 4.0" HALLITE "81"
HKBS 81-659433017.1
O RING BS 248 70 DURO - 5"HKBS ORING248-7017.2
BACK UP FOR O RING BS 24 - 5"HKBS/ORINGBU24817.3
PTE ROD 12" x 55mm(1.75" UNF)HLFEG550
1
8
CLEVIS 1.25"PIN 1.75"UNF
HMCBA00119
CAP NUT 5" - 55mm ROD
HNAP50X55110
BARREL 5 X 12HNBP50X12111
PISTON 5.0" PHASINGHNPP500P
1
12
PHASING VALVE FOR PTE CYINDERHNZA0000
1
13
HEADED BUSHMDAEA006214
HYD. CYLINDER 5 X 12 DS 55 ROD
L:\Inventor\Parts\HZ-\HZP500-12D55.idw
7.1
7.6
7.2
7.3
7.4
7.5
6
3
14
4
7.7
HZP500-12D55
11
6
5
13
8
10
