Grizzly DEEP DIGGER User Manual

53
Specications are subject to change without prior notication December 2019
DESCRIPTIONPART NO.QTYITEM
STRAIGHT GREASE NIPPLE 6mm BMAAA00621
SET SCREW 6 X 15FABDA01622
PIN 1 1/4" ANTI ROT. GREASABLEFGHPA07223
RAM PIN CLIPFKBDA00024
PTE S/KIT SHP STD 5.5" X 2.25"
HKRB000015
PISTON SEAL 5.5" HALLITE "53"HKBS 53-6594410115.1
O RING BS 030 90 DURO - 2"HKAS/ORING030-9015.2
O RING BS 252 70 DUROHKBS ORING252-70
1
5.3
BACK UP FOR O RING BS 252HKBS ORINGBU25215.4
O RING BS 160 70 DUROHKBS ORING160-7015.5
ROD SEAL "513"2.25"X2.75"X.375HKAS 513-883871015.6
ROD WIPER "520"2.25"X2.75X.25HKAS 520-888161015.7
PTE ROD 12" x 2.25mm(1.75"
UNF)
HLFEG225
1
6
CLEVIS 1.25"PIN 1.75"UNF
HMCBA00117
HEADED BUSHMDAEA00629
CAP NUT 5.5" - 2.25"RODHNAP55X225
1
10
PISTON 5.5" PHASINGHNPP550P
111
HYD. CYLINDER 5.5 X 12 DS 2.25"
ROD
HNBP55X12111
HYD. CYLINDER 5.5 X 12 DS 2.25" ROD
L:\Inventor\Parts\HZ-\HZP550-12D.idw
3
1
9
2
7
5.7
5.6
5.4
5.3
5.5
5.1
5.2
6
HZP550-12D
11
10
