Grizzly DEEP DIGGER User Manual

56
Specications are subject to change without prior notication From serial number 7027
DESCRIPTIONPART NOQTYPOS
GREASE NIPPLE 1/8 BSP BMCAA00021
SPRING RETAINERCCDDA002
12
BOLT M20 X 75 pc 8.8 COARSEFABJA07563
BOLT M20 X 80 pc 8.8 COARSEFABJA08024
NYLOC NUT M20 P TYPE 2.5
FFBJA00085
EXTENSION SPRING 98 X 25 X 3.15FHKDC09116
M20 WASHER 3/4" F436 HARDFMCJG000107
8mm D SHACKLE FYBCC00018
CAT 3 FLOPPY SWIVEL TONGUEGPCBF00019
ARTIC. PULL SIDE PLATE ASSYGPFAB000
210
ARTICULATED PULLS
L:\Inventor\Parts\GP-\GPALL.idw
54 THRU
41 THRU
73 THRU
34 THRU
9
0
8
2
8
2
6
2
GPCBF000 CAT 3
ARTICULATED TONGUE
GPEBF000 CAT 5
ARTICULATED TONGUE
GPDBF000 CAT 4
ARTICULATED TONGUE
GPBBF000 CAT 1-2
ARTICULATED TONGUE
GPCATA3 CAT 3
ARTICULATED PULL ASSY.
GPCATA1-2 CAT 1-2
ARTICULATED PULL ASSY.
GPCATA4 CAT 4
ARTICULATED PULL ASSY.
GPCATA5 CAT 5
ARTICULATED PULL ASSY.
10
9
2
8
6
10
FIT SEAL BACKWARDS TO ALLOW GREASE TO PASS.
80 THRU
9
0
GPEBF00C CONSTRUCTION TONGUE
75mm PIN (PAINTED GOLD)
GPCATA5C
CONSTRUCTION ARTIC
PULL ASSY
