Grizzly G0453 User Manual

-47-
READ ELECTRICAL SAFETY
ON PAGE 46!
G0453/G0454 (Mfg. Since 3/08)
2T1
6T3
NO14
4T2
2T1
6T3
4T2
1L1
5L3
NO13
3L2
17
18
97
98
95
96
A1
A2
A2
OL Relay
NHD BTH-25
ON
OFF
Grnd
Contactor
NHD 09D
220V
NEMA 6-20 Plug
(As Recommended)
Magnetic ON/OFF Switch
Hot
Ground
Hot
G
Motor
Grnd
Start Capacitor
200MFD 250VAC
Run Capacitor
20MFD 400VAC
The motor wiring shown here is
current at the time of printing, but it
may not match your machine.
Always use the wiring diagram
inside the motor junction box.
19
20
21
18
17
G0453 Wiring Diagram
wiring diagram g0453

Grizzly G0453 Specifications

General

Brand	Grizzly
Model	G0453
Category	Planer
Language	English
