Grizzly G0462 Manual Addendum

-4-
G0462 Wood Lathe w/Digital Readout
Design Type: .................................................................................................. Floor Model
Overall Dimensions:
Including Stand ..........................................................................69"L x 16"D x 46"H
Floor to Center Height .........................................................................................43"
Footprint ...................................................................................................54" x 13
3
⁄4"
Box 1 Size ........................................................................... 15
3
⁄4"W x 17"H x 63
3
⁄4"L
Box 2 Size ........................................................................... 15
3
⁄4"W x 10"H x 32
3
⁄4"L
Total Shipping Weight .................................................................................. 304 lbs.
Machine Weight ........................................................................................... 287 lbs.
Specifications:
Swing Over Bed ...................................................................................................16"
Distance Between Centers ..................................................................................43"
Spindle Size ........................................................................................ 1" x 8 TPI RH
Spindle Bore Size ................................................................................................
3
⁄8"
Spindle Taper ..................................................................................................MT#2
Tailstock Taper .................................................................................................MT#2
Spindle Speeds ........................................................... 10 Speeds: 600–2400 RPM
Headstock Swivel Range ...................................................... 0˚, 60˚, 90˚, 120˚, 180˚
Construction:
Bed ................................................................................Precision Ground Cast Iron
Stand ......................................................................................................... Cast Iron
Spindle ........................................................Shielded and Lubricated Ball Bearings
Headstock .................................................................................................. Cast Iron
Tailstock ..................................................................................................... Cast Iron
Main Motor:
Type ....................................................................... TEFC Capacitor Start Induction
Horsepower ...................................................................................................... 2 HP
Voltage .............................................................................................................. 110V
Phase/Cycle ...................................................................................... Single / 60 Hz
Amps ........................................................................................................... 14 Amps
RPM ......................................................................................................... 1725 RPM
Bearings ......................................................Shielded and Lubricated Ball Bearings
Switch .......................................................................... Paddle Type w/Lockout Key
Recommended Circuit & Breaker Size ......................................................20 Amps
Features:
................................................................................................ Digital RPM Readout
MODEL G0462 WOOD LATHE W/DIGITAL READOUT
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
MACHINE DATA
SHEET
