Fence & Blade Guides Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0640X001 BUSHING 142 P0640X142 SLIDING PLATE
6 PSS26M SET SCREW M5-.8 X 6 143 PN04M HEX NUT M4-.7
96 PFH31M FLAT HD SCR M4-.7 X 8 144 P0640X144 GUIDE POST RACK
121 P0640X121 FENCE ASSEMBLY 590MM 145 P0640X145 GUIDE POST
121-1 P0640X121-1 FRONT RAIL 640MM 146 P0640X146 GUIDE POST HANDWHEEL
121-2 P0640X121-2 FENCE BASE 147 PCAP02M CAP SCREW M6-1 X 20
121-3 P0640X121-3 FIXED SHAFT 149 PS38M PHLP HD SCR M4-.7 X 10
121-4 P0640X121-4 LOCK SHAFT 150 P0640X150 UPPER BLADE GUIDE ASSEMBLY
121-5 P0640X121-5 SPRING PIECE 5 X 34 X 15 X 19MM 150-1 PCAP01M CAP SCREW M6-1 X 16
121-6 P0640X121-6 LOCK HANDLE M8-1.25 X 44 150-2 P0640X150-2 UPPER GUIDE SUPPORT BLOCK
121-7 P0640X121-7 FENCE 590MM 150-3 PSS01M SET SCREW M6-1 X 10
121-8 PW01M FLAT WASHER 8MM 150-4 P0640X150-4 BLADE GUIDE ADJUSTMENT SHAFT
121-9 P0640X121-9 FENCE HANDLE M8-1.25 X 22 150-5 P0640X150-5 UPPER BLADE GUIDE SUPPORT
121-10 P0640X121-10 RAIL PAD 150-6 P0640X150-6 ECCENTRIC SHAFT
121-11 P0640X121-11 CONVEX WINDOW 150-7 PR05M EXT RETAINING RING 15MM
121-12 PCAP06M CAP SCREW M6-1 X 25 150-8 P6202ZZ BALL BEARING 6202ZZ
121-13 P0640X121-13 LOCK BLOCK 150-9 P0640X150-9 KNURLED KNOB BUSHING
121-14 P0640X121-14 REAR RAIL 640MM 150-10 PCAP48M CAP SCREW M6-1 X 35
121-15 PN03M HEX NUT M8-1.25 150-11 P0640X150-11 SUPPORT BEARING SHAFT
121-16 PFS04M FLANGE SCREW M4-.7 X 6 151 P0640X151 LOWER BLADE GUIDE ASSEMBLY
121-17 P0640X121-17 FRONT RAIL END PLATE 151-1 P0640X151-1 LOWER BLADE GUIDE SUPPORT
121-18 P0640X121-18 T-SLOT NUT R10 SLOT M8 X 1.25 151-2 PCAP01M CAP SCREW M6-1 X 16
121-19 P0640X121-19 REAR RAIL END PLUG 151-3 P0640X151-3 ECCENTRIC SHAFT
121-20 PHTEK3M TAP SCREW M3.5 X 8 151-4 PR05M EXT RETAINING RING 15MM
121-21 P0640X121-21 FENCE SCALE 151-5 P6202ZZ BALL BEARING 6202ZZ
121-22 PN01M HEX NUT M6-1 151-6 P0640X151-6 KNURLED KNOB BUSHING
121-23 PLW03M LOCK WASHER 6MM 151-7 PCAP48M CAP SCREW M6-1 X 35
121-24 PCAP69M CAP SCREW M6-1 X 24 152 P0640X152 MITER GAUGE ASSEMBLY
121-25 PB08M HEX BOLT M6-1 X 20 173 P0640X173 CAST-IRON TRUNNION ASSEMBLY
121-26 PFB13M FLANGE BOLT M4-.7 X 8 173-1 PW01M FLAT WASHER 8MM
121-27 PW03M FLAT WASHER 6MM 173-2 PLN04M LOCK NUT M8-1.25
121-28 P0640X121-28 RESAW FENCE 590MM 173-3 PCB10M CARRIAGE BOLT M8-1.25 X 85
121-29 P0640X121-29 SPACER PLATE 173-4 P0640X173-4 UPPER TRUNNION
122 P0640X122 GEAR 12T/20T 173-5 PCB23M CARRIAGE BOLT M8-1.25 X 80
123 P0640X123 GEAR BOLT 173-6 P0640X173-6 LOCK HANDLE M8-1.25
124 P0640X124 GUIDE BRACKET COVER 173-7 P0640X173-7 ANGLE LABEL
125 PCAP11M CAP SCREW M8-1.25 X 16 173-8 PW01M FLAT WASHER 8MM
126 P0640X126 TABLE 17" X 24" 173-9 PB07M HEX BOLT M8-1.25 X 25
127 T24384 TABLE INSERT 173-10 PW05M FLAT WASHER 4MM
128 P0640X128 TABLE PIN 8 X 29 X R4.5 173-11 P0640X173-11 TABLE TILT POINTER
129 P0640X129 HANDWHEEL BUSHING 173-12 PS17M PHLP HD SCR M4-.7 X 6
130 P0640X130 BUSHING 173-13 P0513109 ADJUSTMENT KNOB BOLT M6-1
131 PBHS22M BUTTON HD CAP SCR M8-1.25 X 20 173-14 PN01M HEX NUT M6-1
132 PLW04M LOCK WASHER 8MM 173-15 P0640X173-15 L-BRACKET
133 P0640X133 GUIDE BRACKET 173-16 PFH01M FLAT HD SCR M5-.8 X 15
134 P0640X134 WORM SHAFT 173-17 PCAP01M CAP SCREW M6-1 X 16
135 P0640X135 FIXED PLATE 173-18 PCAP37M CAP SCREW M6-1 X 50
136 PCAP50M CAP SCREW M5-.8 X 10 173-19 P0640X173-19 TRUNNION SUPPORT BRACKET
137 PW02M FLAT WASHER 5MM 173-20 PBHS19M BUTTON HD CAP SCR M10-1.5 X 30
138 P0640X138 PROTECT COVER 173-21 P0640X173-21 RIGHT BLADE GUARD
139 PCAP01M CAP SCREW M6-1 X 16 173-22 P6000ZZ BALL BEARING 6000ZZ
140 P0640X140 STEP SCREW M4-.7 X 5 173-23 PW04M FLAT WASHER 10MM
141 P0640X141 FIBER WASHER 6 X 13MM
