Grizzly G0651 User Manual

-2-
G0651 & G0652 Update (Mfd. Since 5/17)
Ground
Run
Capacitor
50MFD
250VAC
Start
Capacitor
300MFD
125VAC
220V Motor
NO 13
L2 3 L3 5L1 1
A
T1 2 T2 4 T3 6
NC21
NC22
NO 14
18
15
12
3/41/2 5/6
14
13
24 23
B
9896
95
Magnetic Switch
Assembly MPE-18
Angle Sensor
Digital Readout
AC2
R18
AC1
SDE
MA-18
OFF
On/Off Switch
ON
Hot
Hot
Ground
220
VAC
6-15 Plug
(Included)
220 VAC
SDE RA-20
G
Installation work and
electrical wiring
must be done by
qualified electrician
in accordance with
all applicable codes
and standards.
(Figure 149,
Page 83)
(Figure 150, Page 83)
(Figure 147, Page 83)
Figure 151. G0651
capacitors.
(Figure 148, Page 83)
(Figure 150, Page 83)
(Replaces Page 84)
Updated G0651 Wiring Diagram 220V, 1-Ph

Grizzly G0651 Specifications

General

Brand	Grizzly
Model	G0651
Category	Saw
Language	English
