Grizzly G0651 User Manual

Model G0651/G0652 (Mfg. since 1/10)
-89-
REF PART # DESCRIPTION REF PART # DESCRIPTION
7 PLW04M LOCK WASHER 8MM 58 P0651058 LEFT BEVEL GEAR
15 PSB40M CAP SCREW M8-1.25 X 35 59 PW04M FLAT WASHER 10MM
16 PB06M HEX BOLT M8-1.25 X 12 60 PLN10M LOCK NUT M10-1.25
16-1 PW01M FLAT WASHER 8MM 61 P0651061 LEFT SUPPORT
17V2 P0661042V2 RIVING KNIFE V2.01.10 61-1 P0651061-1 RIGHT SUPPORT
20 P0651020 STRAIN RELIEF PGA 16-14B 62 PN03M HEX NUT M8-1.25
22 PN02M HEX NUT M10-1.5 63 PS14M PHLP HD SCR M6-1 X 12
23 PLW06M LOCK WASHER 10MM 64 P0651064 TILT ARROW POINTER
24 PW04M FLAT WASHER 10MM 65 PTLW05M EXT TOOTH WASHER 6MM
25 P0651025 SPECIAL MOTOR BOLT 66 PK14M KEY 5 X 5 X 18
26 PK12M KEY 5 X 5 X 30 67 PSB31M CAP SCREW M8-1.25 X 25
27 P0651027 FLAT BELT 180J-9 68 P0651068 HEIGHT HANDWHEEL MTG PLATE
28 PSS03M SET SCREW M6-1 X 8 69 P0651069 LOCK KNOB
29 P0651029 PULLEY 70 P0651070 HANDWHEEL
30 P6004-2RS BALL BEARING 6004-2RS 71 P0651071 LOCK COLLAR
31V2 P0661044V2 CLAMPING BRACKET V2.01.10 72 P0651072 FLAT WASHER 19MM
31V2-1 P0661044V2-1 MOUNTING BASE V2.01.10 73 P0651073 BLADE HT HANDWHEEL SHAFT
31V2-2 PCAP14M CAP SCREW M8-1.25 X 20 74 P0651074 ALIGNMENT PIN
31V2-3 P0661044V2-4 LOCKING BOLT V2.01.10 75 PB20M HEX BOLT M8-1.25 X 35
31V2-4 P0661044V2-3 COMPRESSION SPRING V2.01.10 76 P0651076 RIGHT BEVEL GEAR
31V2-5 P0661044V2-5 MOUNTING PLATE V2.01.10 77 PSB06M CAP SCREW M6-1 X 25
31V2-6 PSS31M SET SCREW M5-.8 X 8 78 PLW03M LOCK WASHER 6MM
31V2-7 PBHS16M BUTTON HD CAP SCR M5-.8 X 16 80 P0651080 ON/OFF SWITCH ASSEMBLY
31V2-8 P0661044V2-8 HANDLE V2.01.10 80-1 P0651080-1 ON/OFF PUSH BUTTON SWITCH
31V2-9 PLW01M LOCK WASHER 5MM 80-2 P0651080-2 ON/OFF SWITCH BRACKET
31V2-10 PBHS06M BUTTON HD CAP SCR M5-.8 X 12 80-3 P0651080-3 ON/OFF SWITCH BOX
33 PSB11M CAP SCREW M8-1.25 X 16 80-4 P0651080-4 ON/OFF SWICH CORD 16AWG X 4C
35 P0651035 STICK 80-6 P0651080-6 SWITCH DISABLING LOCK
36 P0651036 BUSHING 81 P0651081 NYLON SCREW 3/16-24 X 1/2
37 PK14M KEY 5 X 5 X 18 116 P0651116 HANDWHEEL HANDLE
38 P0651038 ARBOR SHAFT 117 PWR810 WRENCH 8 X 10
39 P0651039 BLADE 10" X 40T 118 PWR1113 WRENCH 11 X 13
40 P0651040 ARBOR FLANGE 119 PWR1417 WRENCH 14 X 17
41 P0651041 ARBOR NUT 120 PAW03M HEX WRENCH 3MM
42 PSB72M CAP SCREW M10-1.5 X 30 121 PAW04M HEX WRENCH 4MM
43 P0651043 TRUNNION SLIDE 122 PAW05M HEX WRENCH 5MM
44 P0651044 TRUNNION 123 PAW06M HEX WRENCH 6MM
46 P0651046 DUST CHUTE 124 P0651124 SCREWDRIVER PHLP/FLAT HD #1
47 PS06M PHLP HD SCR M5-.8 X 20 130 P0651130 BODY
48 P0651048 MOTOR PULLEY 131 P0651131 DUST CHUTE HOSE 64 X 1000MM
49 P0651049 BRACKET 147 P0651147 SPECIAL SCREW
50 PB03M HEX BOLT M8-1.25 X 16 148 P0651148 WAVE WASHER
51 PW01M FLAT WASHER 8MM 149 PW04M FLAT WASHER 10MM
52 P0651052 LEADSCREW 151 P0651151 MOTOR CORD 14AWG X 3C
53 P0651053 BUSHING 151 P0652151 MOTOR CORD 14AWG X 4C SJT
54 P0651054 GASKET 152 P0651152 POWER CORD 14AWG X 3C 6-15 PLUG
55 P51102 THRUST BEARING 51102 152 P0652152 PWR CORD 14AWG X 4C SJT W/NO PLUG
56 P0651056 LEADSCREW BRACKET 153 P0651153 WIRE PROTCTR 16 X 20 X 300MM
57 PSS07M SET SCREW M5-.8 X 5
Motor and Arbor Parts List
