To adjust the depth of cut:
1.
Figure 24
Figure 24.
2.
Note:
3.
NOTICE
It is imperative that the elevation lock knob
is fully tightened before resuming the sand-
ing process. Otherwise, the sanding drum
will raise up under the pressure from the
workpiece and will not evenly sand it.
Depth of Cut
Important: Keep in mind that, although the thick-
ness of the workpiece is reduced during sanding,
this process is not a replacement for thickness
planing, which should be done with a planer or
other acceptable tool/machine before beginning
the sanding process.
NOTICE
Taking an excessive depth of cut could
cause the sanding motor to exceed the
available power source amperage. In this
case, the motor or power source circuit
breaker will trip. If this should happen, dis-
connect the machine from power, allow the
motor to cool, reset the circuit breaker, then
take a smaller depth of cut.
