Model G0750G (Mfg. Since 11/12)
-93-
Headstock Controls Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
201 P4003G0175 HEADSTOCK OIL FILL PLUG M16-2.0 228 P4003G1102 FRONT CONTROL PLATE
202 P4003G0176 HEADSTOCK COVER 229 PSS04M SET SCREW M6-1 X 12
203 PCAP06M CAP SCREW M6-1 X 25 230 P0750G0230 HANDWHEEL HANDLE M8-1.25 X 40
204 P4003G0178 HEADSTOCK COVER GASKET 232 P4003G1106 HANDLE HUB
205 PRP05M ROLL PIN 5 X 30 233 P4003G1107 HANDLE HUB PLATE
206 PR03M EXT RETAINING RING 12MM 234 PSTB003M STEEL BALL 6MM
207 P4003G0181 SHIFTING ARM 235 P4003G1109 COMPRESSION SPRING 1.2 X 4.8 X 27
208 P4003G0182 SHIFTING FORK 236 PSS20M SET SCREW M8-1.25 X 8
209 PSS06M SET SCREW M8-1.25 X 16 237 PRP28M ROLL PIN 5 X 40
210 PN03M HEX NUT M8-1.25 238 P4003G1112 FEED DIRECTION HANDLE M10-1.5 X 10
211 PRP49M ROLL PIN 5 X 25 239 P4003G1113 FEED DIRECTION HUB PLATE
212 P4003G0186 GEAR 38T 240 P4003G1114 COMPRESSION SPRING 1 X 5 X 16
213 P4003G0187 O-RING 11.2 X 2.65 241 P4003G1115 FEED DIRECTION HANDLE HUB
214 P4003G0188 PINION SHAFT 242 P4003G1116 HEADSTOCK OIL DRAIN PLUG 3/8" NPT
215 PK94M KEY 5 X 5 X 8 243 PSS01M SET SCREW M6-1 X 10
216 P4003G0190 SHAFT 244 PSS03M SET SCREW M6-1 X 8
217 P4003G0191 COLLAR 245 P4003G1119 END GEAR COVER
218 P4003G0192 SHIFTING ARM 246 P0750G0246 END COVER TOP BOLT M10-1.5 X 80
219 P4003G0193 SHIFTING FORK 247 P0750G0247 SPIDER GUARD THUMB NUT M10-1.5
220 P4003G0194 SHAFT 248 P0750G0248 SPIDER GUARD HEX NUT M16-2
221 PCAP04M CAP SCREW M6-1 X 10 249 P0750G0249 SPIDER GUARD STUD-FT M16-2 X 40
222 PCAP13M CAP SCREW M8-1.25 X 30 250 P0750G0250 SPIDER GUARD
224 P4003G0198 HEADSTOCK OIL SIGHT GLASS A12 251 PEC05M E-CLIP 15MM
225 PW06M FLAT WASHER 12MM 252 P0750G0252 KNURLED HEAD THUMB SCREW M10-1.5
226 PCAP77M CAP SCREW M12-1.75 X 30 253 P0750G0253 SPIDER GUARD BOLT KNOB M8-1.25 X 14
227 PS12M PHLP HD SCR M3-.5 X 6 254 PCAP01M CAP SCREW M6-1 X 16
