Grizzly G0750G Parts List

Model G0750G (Mfg. Since 11/12)
-95-
Quick-Change Gearbox Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
301 P6203-2RS BALL BEARING 6203-2RS 345 P0750G0345 SHIFT FORK A RACK
302 P0750G0302 SPACER 346 P0750G0346 SHIFT FORK B
303 PR06M EXT RETAINING RING 16MM 347 P0750G0347 SHIFT FORK B RACK
304 P0750G0304 COMBO GEAR 16T/24T 348 P0750G0348 O-RING 12 X 1.9
305 P6202-2RS BALL BEARING 6202-2RS 349 P0750G0349 SHIFT FORK C
306 P0750G0306 SPACER 350 P0750G0350 SHIFT FORK C RACK
307 PR09M EXT RETAINING RING 20MM 351 P0750G0351 SHIFT FORK D RACK
308 PR19M EXT RETAINING RING 28MM 352 PSS49M SET SCREW M4-.7 X 16
309 P0750G0309 GEAR 24T 353 PN04M HEX NUT M4-.7
310 P0750G0310 GEAR 28T 354 P0750G0354 SHIFT FORK D
311 PK38M KEY 4 X 4 X 22 355 P0750G0355 SHIFT FORK SHAFT
312 P0750G0312 GEAR 18T 356 P0750G0356 GEAR 32T
313 P0750G0313 GEARBOX FILL/DRAIN PLUG 3/8" NPT 357 P0750G0357 GEAR 16T
314 P6004-2RS BALL BEARING 6004-2RS 358 P0750G0358 GEAR 24T
315 P0750G0315 LEADSCREW BEARING COVER GASKET 359 P0750G0359 TAPERED PIN 8 X 26
316 P0750G0316 LEADSCREW BEARING COVER 360 PCAP31M CAP SCREW M8-1.25 X 25
317 PCAP33M CAP SCREW M5-.8 X 12 361 P0750G0361 LOWER GEARBOX SPLINED SHAFT
318 P0750G0318 OIL SEAL 25 X 40 X 7 362 P0750G0362 UPPER GEARBOX SHAFT
319 P0750G0319 LEADSCREW SHAFT 363 PK184M KEY 4 X 4 X 55
320 P0750G0320 KEY 4 X 4 X 145 364 PK14M KEY 5 X 5 X 18
321 P0750G0321 SHAFT 365 PCAP01M CAP SCREW M6-1 X 16
322 P0750G0322 BEARING COVER GASKET 366 P0750G0366 LWR CHANGE GEAR SHAFT BRACKET
323 P0750G0323 BEARING COVER 367 P0750G0367 GEAR SHAFT BRACKET GASKET
324 PK14M KEY 5 X 5 X 18 368 P0750G0368 OIL SEAL 22 X 35 X 7
325 P0750G0325 FEED ROD SHAFT 369 P0750G0369 LOWER CHANGE GEAR SHAFT
326 P0750G0326 FEED ROD SHAFT BEARING COVER 370 PK33M KEY 5 X 5 X 45
327 P0750G0327 FEED ROD SHAFT GASKET 371 PCAP66M CAP SCREW M8-1.25 X 65
328 P0750G0328 SPINDLE SWITCH COVER 372 PRP73M ROLL PIN 4 X 30
329 P0750G0329 SPINDLE SWITCH ARM 373 P0750G0373 O-RING 7 X 1.9
330 PSS03M SET SCREW M6-1 X 8 374 P0750G0374 PINION SHAFT
331 P0750G0331 LIMIT SWITCH 375 P0750G0375 GEARBOX COVER GASKET
332 PSS26M SET SCREW M5-.8 X 6 376 P0750G0376 GEARBOX COVER
333 P0750G0333 BUTTON HD CAP SCR M4-.7 X 45 377 P0750G0377 GEARBOX OIL SIGHT GLASS A12
334 P0750G0334 GEAR 32T 378 P0750G0378 GEARBOX COVER PLATE
335 P0750G0335 SPACER 379 P0750G0379 GEARBOX DIAL COVER PLATE
336 P0750G0336 GEAR 30T 380 PSS03M SET SCREW M6-1 X 8
337 P0750G0337 GEAR 28T 381 PSS01M SET SCREW M6-1 X 10
338 P0750G0338 GEAR 30T 382 PRP28M ROLL PIN 5 X 40
339 P0750G0339 SPACER 383 P0750G0383 GEARBOX DIAL
340 P0750G0340 GEAR 16T 384 P0750G0384 COMPRESSION SPRING 1 X 5 X 20
341 P0750G0341 GEAR 32T 385 PSTB003M STEEL BALL 6MM
342 PEC05M E-CLIP 15MM 386 PS07M PHLP HD SCR M4-.7 X 8
343 P0750G0343 GEAR 32T/16T 387 PCAP38M CAP SCREW M5-.8 X 25
344 P0750G0344 SHIFT FORK A 388 PRP28M ROLL PIN 5 X 40
