Grizzly G0869 User Manual

-60-
Model G0869/G0870 (Mfd. Since 01/19)
BUY PARTS ONLINE AT GRIZZLY.COM !
Scan QR code to visit our Parts Store.
Table & Fence
REF PART # DESCRIPTION REF PART # DESCRIPTION
2 P0869002 FENCE ASSEMBLY 20-2 P0869020-2 HEX NUT M8-1.25
2-1 P0869002-1 FENCE BODY 20-3 P0869020-3 FENCE LOCK PIVOT ASSEMBLY (REAR)
2-2 P0869002-2 FENCE MOUNT BRACKET 21 P0869021 FENCE ADJUSTMENT ASSEMBLY
2-3 P0869002-3 CAP SCREW W/LOCK WASHER M5-.8 X 12 21-1 P0869021-1 LOCK NUT M10-1.5
2-4 P0869002-4 NARROW RIP AUXILIARY FENCE 21-2 P0869021-2 FLAT WASHER 10MM
2-5 P0869002-5 TAP SCREW M4 X 10 21-3 P0869021-3 FENCE ADJUSTMENT DIAL
2-6 P0869002-6 NARROW RIP FENCE PIVOT BRACKET 21-4 P0869021-4 PINNON GEAR 15T
2-7 P0869002-7 FENCE END PLATE (FRONT) 21-5 P0869021-5 BEARING BLOCK
2-8 P0869002-8 SHOULDER SCREW M5-.8 X 10, 8 X 3.5 21-6 P0869021-6 COMPRESSION SPRING 0.6 X 5.5 X 14
2-9 P0869002-9 TAP SCREW M4 X 10 21-7 P0869021-7 PHLP HD SCR W/WASHER M5-.8 X 10
2-10 P0869002-10 FENCE END PLATE (REAR) 21-8 P0869021-8 BEARING BLOCK HOUSING
2-11 P0869002-11 LOCATING PIN 3.5 X 8, 3.3 X 10, 3.3 X 2 21-9 P0869021-9 BEARING BLOCK SUPPORT BRACKET
2-12 P0869002-12 FENCE BASE BRACKET 21-10 P0869021-10 ROLL PIN 4 X 16
3 P0869003 TABLE INSERT ASSEMBLY 21-11 P0869021-11 E-CLIP 10MM
3-1 P0869003-1 TABLE INSERT 21-12 P0869021-12 PINION SHAFT
3-5 P0869003-5 SET SCREW M5-.8 X 12 22 P0869022 PHLP HD SCR W/WASHERS M5-.8 X 14
4 P0869004 TABLE INSERT LOCK 23 P0869023 CAP SCREW W/LOCK WASHER M5-.8 X 12
5 P0869005 WAVY WASHER 6MM 24 P0869024 EXTENSION SHAFT MOUNTING BLOCK
6 P0869006 FLAT WASHER 5MM 25 P0869025 TRUNNION BRACKET (REAR)
7 P0869007 LOCK NUT M5-.8 26 P0869026 CAP SCREW W/WASHERS M6-1 X 15
8 P0869008 RAIL (FRONT) 27 P0869027 TRUNNION
9 P0869009 FENCE SCALE INDICATOR 28 P0869028 MOUNTING PLATE
10 P0869010 PHLP HD SCR W/WASHER M4-.7 X 8 29 P0869029 TRUNNION BRACKET (FRONT)
11 P0869011 SHOULDER SCREW M5-.8 X 6, 6.5 X 3 30 P0869030 ACORN NUT M6-1
12 P0869012 KNOB BOLT M5-.8 X 10, D20, ROUND KN 31 P0869031 GUARD STORAGE BRACKET A
13 P0869013 PHLP HD SCR W/LOCK WASHER M5-.8 X 16 32 P0869032 KNOB BOLT M6-1 X 20, 6-LOBE, D38
14 P0869014 RAIL MOUNTING BAR 35 P0869035 TABLE EXTENSION ASSEMBLY
15 P0869015 TABLE 35-1 P0869035-1 TABLE EXTENSION REST
16 P0869016 RAIL (REAR) 35-2 P0869035-2 TABLE EXTENSION SHAFT
17 P0869017 FENCE LOCK ASSEMBLY (FRONT) 35-3 P0869035-3 E-CLIP 9MM
17-1 P0869017-1 LOCK NUT M5-.8 35-4 P0869035-4 COTTER PIN 1/4-1/2 X 1-3/4 HAIRPIN
17-2 P0869017-2 FLAT WASHER 5MM 35-5 P0869035-5 FLAT WASHER 6MM
17-3 P0869017-3 FENCE LOCK PIVOT ASSEMBLY (FRONT) 35-6 P0869035-6 PHLP HD SCR M6-1 X 10
17-4 P0869017-4 BUSHING 42 P0869042 MITER GAUGE ASSEMBLY
17-5 P0869017-5 FENCE LOCK SHAFT 42-1 P0869042-1 KNOB BOLT M6-1 X 13, D20, ROUND
17-6 P0869017-6 HEX BOLT M5-.8 X 25 42-2 P0869042-2 FLAT WASHER 5 X 14 X 1.5MM (PLASTIC)
17-7 P0869017-7 ROLL PIN 4 X 22 42-3 P0869042-3 PHLP HD SCR M5-.8 X 6
17-8 P0869017-8 FENCE LOCK LEVER 42-4 P0869042-4 MITER GAUGE SCALE POINTER
17-9 P0869017-9 FLAT WASHER 6MM 42-6 P0869042-6 MITER GAUGE BODY
17-10 P0869017-10 LOCK NUT M6-1 42-7 P0869042-7 SHOULDER SCREW M5-.8 X 6, 7.5 X 3.25
18 P0869018 FLAT WASHER 8MM 42-8 P0869042-8 MITER BAR
19 P0869019 COMPRESSION SPRING 2.6 X 13.8 X 30 50 P0869050 COMPRESSION SPRING 0.8 X 8.6 X 30
20 P0869020 FENCE LOCK ASSEMBLY (REAR) 65 P0869065 FLAT WASHER 7MM
20-1 P0869020-1 STANDOFF-HEX M8-1.25, 50 89 P0869089 FENCE SCALE
