Model G0893 (Mfd. Since 2/21)
(Replaces Page 14 in Manual)
NOTICE
If you cannot find an item on this list, care-
fully check around/inside the machine and
packaging materials. Often, these items get
lost in packaging materials while unpack-
ing or they are pre-installed at the factory.
The following is a list of items shipped with your
machine. Before beginning setup, lay these items
out and inventory them.
If any non-proprietary parts are missing (e.g. a
nut or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store.
Jointer Inventory (Figures
5–6)
Qty
A. Jointer Bed Assembly ................................ 1
B.
Fence ......................................................... 1
C.
Carriage Assembly ..................................... 1
D.
Dust Chute ................................................. 1
E.
Dust Collection Bag Clamp ........................ 1
F.
Dust Collection Bag .................................... 1
G.
Push Blocks ................................................ 2
H.
Handles ...................................................... 2
I.
Fence Carriage Lock Lever ........................ 1
J.
Fence Tilt Lock Lever ................................. 1
K.
Replacement Inserts (5-Pack) .................... 1
L.
Carriage Mounting Bracket ........................ 1
M.
Limit Block .................................................. 1
N.
Locking Pin Plate ....................................... 1
O.
Hex Wrenches 5, 6mm .........................1 Ea.
P.
T-Handle Torx Wrench T25 ........................ 1
Q.
Beveled Washers 10 x 3.5mm ................... 2
R.
Cap Screws M8-1.25 x 30 w/Washers ....... 4
S.
Cap Screws M8-1.25 x 20 w/Washers ....... 2
T.
Flat Head Torx Screws M5-.8 x 10 .......... 10
Figure 5. Jointer bed assembly.
A
Inventory
Figure 6. Small components.
B
F
E
G
H
I
J
C
D
K
L
M
N
P
Q
R
O
S
T
