Grizzly G0941 - Page 5

Model G0941 (Mfd. Since 09/20)
-5-
M
Figure 4. Fence components.
L
Fence Rail
Box Contents (Figure 5) Qty
N. Fence Guide Tube ...................................... 1
O.
Front Rail 75" .............................................. 1
P.
Rear Rail 62
1
⁄2" ........................................... 1
Figure 5. Fence rail components.
N
O
P
Fence
Box Contents (Figure 4) Qty
L. Fence ......................................................... 1
M.
Fence Handle ............................................. 1
Fasteners (and where used):
Qty
• Hex Bolts M8-1.25 x 25 (Extension Wing) . 4
• Lock Washers 8mm (Extension Wing) ....... 4
• Flat Washer 8mm (Miter Gauge)................ 1
• Hex Bolts M8-1.25 x 12 (Fence Brackets) . 2
• Hex Bolts M8-1.25 x 12 (Switch) ................ 2
• Flat Head Screws M8-1.25 x 25 (Rails) ..... 6
• Lock Washers 8mm (Rails) ...................... 10
• Hex Nuts M8-1.25 (Rails) ........................... 4
• Cap Screws M8-1.25 x 25 (Rails) .............. 6
• Flat Washers 8mm (Rails) .......................... 6
• Hex Bolts M8-1.25 x 12 (Guide Tube) ....... 7
