Grizzly G0869 - User Manual

Questions and Answers

E
Eric ShafferAug 16, 2025
Why is too much sawdust blown back toward the operator on my Grizzly Saw?
- B
  Barbara DelgadoAug 16, 2025
  Excessive sawdust blowing back towards the operator of your Grizzly Saw can occur due to several reasons: * The blade guard may be removed. Re-install the blade guard to maximize safety and dust control. * There may be too many air leaks in the cabinet, preventing proper dust collection. Seal any leaks in the cabinet or around the blade guard dust port. * The dust collection system might be clogged or lack the required CFM at the machine. Remove any clogs, revise the ducting layout to improve suction, or consider using a different dust collector.
C
courtney96Aug 19, 2025
Why does the board bind or burn when feeding through my Grizzly Saw?
- K
  Kimberly MillerAug 19, 2025
  If the board binds or burns when feeding it through your Grizzly Saw, it could be due to: * A warped, damaged, or dull blade. Consider replacing the blade. * Too many teeth on the blade for the type of cut you're making. Try changing to a blade with fewer teeth. * The riving knife or spreader is not correctly aligned with the blade. Adjust the riving knife or spreader to align it properly with the blade.
C
Carol CarterAug 22, 2025
How to fix a Grizzly Saw rip fence that does not move smoothly?
- A
  Ashley Hernandez MDAug 22, 2025
  If the rip fence on your Grizzly Saw isn't moving smoothly, here are a few things to check: * Ensure the fence lock lever is fully disengaged. * The front or rear rack and pinion might be dirty or sticky. Clean them thoroughly. * The rails themselves could be dirty or sticky. Clean and wax the rails to ensure smooth movement.
C
Carol GardnerAug 25, 2025
What to do if the blade tilt on my Grizzly G0869 Saw does not stop at 45 or 90 degrees?
- D
  David TerrellAug 26, 2025
  If the blade tilt on your Grizzly Saw doesn't stop correctly at 45° or 90°, the issue could be: * The 45°/90° blade tilt stop is out of adjustment. Adjust the 45°/90° stop. * Sawdust has built up in or on the trunnions. Remove the sawdust from the trunnions, and clean and re-lubricate as necessary.
F
fletcherryanAug 28, 2025
What to do if the blade hits the table insert when tilting my Grizzly G0869 to 45 degrees?
- B
  Bradley RileyAug 28, 2025
  If the blade of your Grizzly Saw hits the table insert when tilting to 45°, consider the following: * Sawdust or debris may be stuck in the trunnion slides. Clean out any sawdust or debris from the trunnion slides. * The blade may be incorrectly installed. Make sure the blade is correctly installed.
P
Pamela ThomasAug 31, 2025
Why does the material move away from the fence when ripping on my Grizzly G0869 Saw?
- D
  Dr. David Smith DDSAug 31, 2025
  If the material moves away from the fence when ripping on your Grizzly Saw, it may be due to improper feeding technique. It is recommended to learn and use the proper feeding technique.
S
Stacy MccoySep 3, 2025
Why is the blade not parallel with the miter slot on my Grizzly Saw?
- R
  Rebecca WagnerSep 3, 2025
  If the blade isn't parallel with the miter slot on your Grizzly Saw, it might be because the blade is warped, damaged, or dull. If that's the case, replace the blade.
C
Chris CarrollSep 6, 2025
What to do if the workpiece catches on the table/dado insert of my Grizzly G0869 Saw during cutting?
- M
  Michael RiddleSep 6, 2025
  If the workpiece catches on the table/dado insert or table throat during a cutting operation with your Grizzly Saw, the table/dado insert may be out of adjustment. Adjust the table/dado insert so it is perfectly flush with the table surface.
R
Rodney CarrSep 8, 2025
Why is the blade too close to the insert on my Grizzly Saw?
- B
  browndebraSep 9, 2025
  If the blade is too close to the insert on your Grizzly Saw, it might be because the blade or arbor washers are incorrectly installed on the arbor. Verify that the blade and arbor washers are correctly installed in the required positions.
P
Paul CollinsSep 12, 2025
What to do if the blade will not move up or down on my Grizzly G0869 Saw?
- N
  nowensSep 12, 2025
  If the blade on your Grizzly Saw will not move up or down, the set screw on the pinion gear may be loose or missing. Try to tighten or replace the set screw.
