Grizzly G1022PRO - G1022 Z Machine Data

-52- G1022 Series Contractor Saws
Design Type ......................................................................................................Floor Model
Overall Dimensions:
Table Height ............................................................................................................37"
Table Size ........................................................................................27
1
⁄8" D x 20
1
⁄8" W
Table Size With Extension Wings ....................................................27
1
⁄8" D x 40
5
⁄8" W
Table With Wings and Fence Rails ........................................................48" W x 44" D
Miter Gauge T-Slot ............................................................................................
3
⁄8" x
3
⁄4"
Weight (Net) ......................................................................................................240 lbs.
Weight (Shipping)..............................................................................................250 lbs.
Box # 1 Size ............................................................................36" L x 18
1
⁄2" W x 25" H
Box # 2 Size ..................................................................................46" L x 3" W x 2" H
Box # 3 Size ................................................................................12" L x 12" W x 5" H
Footprint ........................................................................................................21" x 25"
Construction:
Table ................................................................................................Ground Cast Iron
Stand ..................................................................................................Pre-formed Steel
Miter Gauge ........................................................................................Aluminum ⁄ Steel
Trunnions ........................................................................................................Cast Iron
Bearings............................................................Shielded and Lubricated Ball Bearings
Fence ..............................Single Lever ; Front & Rear Locking w/ Micro Adjust Knob;
..............................................................Heavy Extruded Aluminum with Tee Slot Top
Rails ..........................................................................44" x 1
3
⁄8" Chrome Plated Tubing
Guard ........................................................................................Steel and Clear Plastic
Wings..............................................................Ground Cast Iron, Open Ribbed Design
Cutting Capacity:
Maximum Blade Diameter ........................................................................................10"
Maximum Depth of Cut at 90° ................................................................................3
1
⁄8"
Blade Tilt ....................................................................................................0°-45° Right
Maximum Depth of Cut at 45° ................................................................................2
1
⁄8"
Maximum Rip to Right of Blade (Standard)..............................................................24"
Maximum Rip to Right of Blade (Optional Extension Rails) ....................................48"
Maximum Rip to Left of Blade ..................................................................................11"
Distance from Front of Table to Center of Blade ....................................................17"
Distance from Front of Table to Front of Blade........................................................12"
Maximum Width of Dado Cut ..................................................................................
13
⁄16"
Motor:
Type ............................................................................TEFC Capacitor Start Induction
Horsepower .................................................................................................... 1
1
⁄2 H.P.
Phase / Cycle ..............................................................................Single Phase ⁄ 60 HZ
Voltage..........................................................................................................110 ⁄ 220V
Prewired ................................................................................................................110V
Amps ..................................................................................................................16 ⁄ 8A
Hertz and R.P.M.............................................................................60Hz ⁄ 3450 R.P.M.
Power Transfer ..............................................................................................Belt Drive
Switch ..........................................................................................ON/OFF Push Button
Arbor:
Dimension........................................................................................................
5
⁄8" x 1
1
⁄4"
Speed ......................................................................................................4,700 R.P.M.
Features:
........................................Includes Table Inserts for Standard Blade and Dado Blade
Specifications, while deemed accurate, are not guaranteed.
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
GRIZZLY MODEL G1022Z TABLE SAW
MACHINE DATA
