Grizzly G1022PRO - G1022 Zf;Zfx;Pro Machine Data

-58- G1022 Series Contractor Saws
Design Type ......................................................................................................Floor Model
Overall Dimensions:
Table Height ............................................................................................................37"
Table Size ........................................................................................27
1
⁄8" D x 20
1
⁄8" W
Table Size With Extension Wings ....................................................27
1
⁄8" D x 40
5
⁄8" W
Overall Dimensions – With Wings and Fence Rails ............................50" D x 52
1
⁄2" W
Miter Gauge T-Slot ............................................................................................
3
⁄8" x
3
⁄4"
Blade Tilt ....................................................................................................0°-45° Right
Weight (Net) ......................................................................................................325 lbs.
Weight (Shipping)..............................................................................................340 lbs.
Box # 1 Size (Base)..............................................................37
1
⁄2" L x 22" W x 22
1
⁄2" H
Box # 2 Size (Fence) ................................................................49" L x 15
1
⁄2" W x 9" H
Box # 3 Size (Accessories) ..........................................................14" L x 14" W x 6" H
Box # 4 Size (Motor) ..............................................................10
1
⁄4" L x 16" W x 9
3
⁄4" H
Footprint ........................................................................................................21" x 25"
Construction:
Table ................................................................................................Ground Cast Iron
Stand ..................................................................................................Pre-formed Steel
Miter Gauge ......................................................Cast Iron ⁄ Steel; Adjusts for Side Play
Trunnions ........................................................................................................Cast Iron
Bearings............................................................Shielded and Lubricated Ball Bearings
Fence ................................................................................................Shop Fox
®
Fence
Guard ........................................................................................Steel and Clear Plastic
Wings..............................................................Ground Cast Iron; Open Ribbed Design
Cutting Capacity:
Maximum Blade Diameter ........................................................................................10"
Maximum Depth of Cut at 90° ................................................................................3
1
⁄8"
Maximum Depth of Cut at 45° ................................................................................2
1
⁄8"
Maximum Rip to Right of Blade (Standard)..............................................................25"
Maximum Rip to Right of Blade (Optional Extension Rails) ....................................48"
Maximum Rip to Left of Blade ..................................................................................11"
Distance from Front of Table to Center of Blade ..................................................17
1
⁄4"
Distance from Front of Table to Front of Blade ....................................................12
1
⁄2"
Maximum Width of Dado Cut ..................................................................................
13
⁄16"
Motor: ZF ZFX PRO
Type...................................................TEFC Capacitor Start Induction............................
Horsepower..............................1
1
⁄2 H.P....................2 H.P....................2 H.P..................
Phase / Cycle................................................Single Phase ⁄ 60 HZ.................................
Voltage................................................................110 ⁄ 220V...........................................
Prewired.....................................110V......................220V.....................220V.................
Amps........................................17 ⁄ 8.5A..................26 / 13A..............26 / 13A...............
R.P.M....................................................................3450 R.P.M........................................
Power Transfer.......................................Power Twist
®
Link Belt Drive...........................
Switch...........................................................ON/OFF Push Button.................................
Arbor:
Dimension........................................................................................................
5
⁄8" x 1
1
⁄4"
Speed ......................................................................................................4,700 R.P.M.
Features:
........................................Includes Table Inserts for Standard Blade and Dado Blade
......................................U.S.A. Motor, 4" Ported Dust Hood, Link Belt, Rail Mounted Switch
Specifications, while deemed accurate, are not guaranteed.
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
GRIZZLY MODEL G1022ZF/ZFX/PRO TABLE SAW
MACHINE DATA
SHEET
